Cost effective Dog ultrasound machine EKONVU32 for sale
MODEL / EKONVU32Cost effective Dog ultrasound machine EKONVU32 for sale. Cheap Dog ultrasound machine EKONVU32 for sale
- Geometric location accuracy
Product Details
Quick Details
Scanning manner: Electronic convex array
Working frequency: 2.5MHz~5MHz
Display mode: B, B+B
Specifications
Cheap Dog ultrasound machine EKONVU32 for sale
Probe: 3.5C8050L Convex Probe
Detection depth: ≥180mm
Dead zone: ≤3 mm
Resolution:
Horizontal:≤2 mm（Depth≤80mm）
Vertical: ≤1mm（Depth≤80mm）
Geometric location accuracy
Horizontal: ≤10%
Vertical: ≤5%
Amplification factor: 1.0, 1.2, 1.5,2.0
Scanning manner: Electronic convex array
Working frequency: 2.5MHz~5MHz
Display mode: B, B+B
Scanning range: Convex array 70°
Image gray-scale: 256 levels
Scanning line number: 512 lines/frame
Frame rate: 30 frames/second
Digital scanning conversion: 512*512*8 bits
Display screen: 5 "-TFT
Overall size: 240mm*117mm*40mm
Total weight: 854g
Battery capacity: 3000mAH/7.4V
Continuous work Over: 2 hours
Power consumption: 7W
Technical Specifications
Technical parameters from the currently available product information.
- Scanning manner
- Electronic convex array
- Working frequency
- 2.5MHz~5MHz
- Display mode
- B, B+B
- Probe
- 3.5C8050L Convex Probe
- Detection depth
- ≥180mm
- Dead zone
- ≤3 mm
- Horizontal
- ≤2 mm（Depth≤80mm）
- Vertical
- ≤1mm（Depth≤80mm）
- Amplification factor
- 1.0, 1.2, 1.5,2.0
- Scanning range
- Convex array 70°
- Image gray-scale
- 256 levels
- Scanning line number
- 512 lines/frame
- Frame rate
- 30 frames/second
- Digital scanning conversion
- 512*512*8 bits
- Display screen
- 5 "-TFT
- Overall size
- 240mm*117mm*40mm
- Total weight
- 854g
- Battery capacity
- 3000mAH/7.4V
Specifications can vary by configuration. Confirm intended use, final model, and supply details with our product team.
