Dual Syringe CT Injector EKONIS34 for sale | Medsinglong

Quick Details

Model: EKONIS34 Syringes:20oml,Dual syringe Power:AC 220V,±10% ， 50±1Hz Environment: Temperature: +5°C~ +40°℃,Humidity:≤93% Weight:35kg Dimensions:Main machine: 1260mm (Height)×530mm (Width)×530mm(Depth)

Specifications

Dual Syringe CT Injector EKONIS34:

Features and Benefits:

Safety function: Unique "Direct Pressure Sensor" detects real-time injection pressure,stop injection automatically if the pressure is abnormal,very helpful to reduce the swelling caused by vascular rupture Synchronization protection, stop machine when occluding "Air exhaustion confirm' button prevent air embolism "Trial injection'button avoid fault operation Soft and hard 'stop'button Sound and optic alarm "Emergency'button

Components Quality: Best quality motor and key parts, long-term working robust. Up-to-date powerful 32x processor,real-time control

Injection functions: Flow rate:o.1-10ml/s,increments 0.1 mlfs Pressure limits: 100-300psi,increments 50psi kvO:0.1 ml/s Scan delay: 0-600s lnjection delay:O-600s Max.8 phases support different injection combination Max.120 injection programs can be stored,recalled and modified 200ml large volume syringe meets most application needs Support saline flushing, which can control the contrast agent reach the right part punctually, reduce the picture interferential shadows during the scan, and make the contrast agent denser to obtain stronger signal

Operability: Local & remote dual monitors, easy to operate. Large true-color touch screen LCD, convenient graphic user interface Extensive in-and output modes can be fitted to various imaging devices Mobile cart convenient for relocation Rotative shine LED indication, show injecting or filling status visually

Components Quality: Best quality motor and key parts, long-term working robust Up-to-date powerful 32x processor,real-time control

Specifications: Model: EKONIS34 Syringes:20oml,Dual syringe Power:AC 220V,±10% ， 50±1Hz Environment: Temperature: +5°C~ +40°℃,Humidity:≤93% Weight:35kg Dimensions:Main machine: 1260mm (Height)×530mm (Width)×530mm(Depth)
