High Frequency Mobile Digital C-arm System EKONCX38 for Radiography

Quick Details

Photography Capacity: Max rated capacity: 3.5 KW Tube Voltage and Current Combination: 40kV～49kV 1 ～180 mAs 50kV～59kV 1 ～140 mAs 60kV～69kV 1 ～125 mAs 70kV～79kV 1 ～110 mAs 90kV～99kV 1 ～80 mAs 100kV～110kV 1 ～63 mAs

Specifications

Features of High Frequency Mobile C-arm System EKONCX38:

1.Leading domestic level Mobile Surgical X-ray machine. Real continuously pulse fluoroscopy 25fps. Convenient connection with the Digital subtraction system。 2.One million pixels CCD camera makes the image more distinct. 3.World-class image processing technology software makes the image more distinct to make it more convenient for the doctors in the operation and diagnostic process. Standard DICOM interface makes it convenient to connect with the hospital information system. 4.The pulse fluoroscopy can obtain high –definition image from low dose to meet the requirement of the high-precision and high difficulty microinvasive operation 5.Low radiation dose used can protect the doctor and patient.

Specification of High Frequency Mobile C-arm System EKONCX38:

1.Fluoroscopic Capacity Max rated capacity: Tube Current 4mA, Tube Voltage 110kV Automatic Fluoroscopy: Tube Voltage:40kV～110kV Adjust;Tube Current: 0.3mA～4mA Manually Setting Manual Fluoroscopy: Continuous Tube Voltage:40kV～110kV;Continuous Tube Current: 0.3mA～4mA Pulse Fluoroscopy: Continuous Tube Voltage 40kV～110kV;Continuous Tube Current 0.3mA～8mA Pulse frequency: 0.1~25fps, Continuously Adjustable

2.Photography Capacity: Max rated capacity: 3.5 KW Tube Voltage and Current Combination: 40kV～49kV 1 ～180 mAs 50kV～59kV 1 ～140 mAs 60kV～69kV 1 ～125 mAs 70kV～79kV 1 ～110 mAs 90kV～99kV 1 ～80 mAs 100kV～110kV 1 ～63 mAs

3.X-ray Tube X-ray Tube Special for High Frequency Fixed anode Dual-focus: small focus: 0.3( Sole Advantage). Large focus:1.5mm Inverter Frequency: 40KHz Thermal capacity: 35KJ(47HU)

4.Video System: ImageIntensifier: Image Intensifier made by TOSHIBA CCD Video camera: 1.0 mega pixels ultra low-light CCD camera imported from Japan. Monitor: 19”&23”, resolution ratio 1290*1080 ，Frequency: 60Hz

5.Image Processing System: (standard): real-time image collection, specular image, recursive level 0-15 continuously adjustable,last frame frozen, Gamma correction, mass storage,image W/L adjustable, gray-scale conversion,interest district balance, reversal, noise reduction,intensify, smooth, sharpen, compress, enlarge,measurement, label, print and typesetting, DicomSCP, DicomSCU, DicomDIR, Dicom Printing,HIS

6.Structure: Directive wheel: ±90°revolution，can freely change the moving direction of the unit. Ascending & Descending Range of Pillar: ≥400mm C-arm: Forward and Backward Movement: 200mm, Revolution around Horizontal Axis: ±180° Revolution around Vertical Axis: ±15°,( Advantage), better than others’ ±12.5°, easier to take special positions radiography ) Focus screen distance:1000mm, C-arm opening:800mm, C-arm arc depth: 640mm Slip on orbit: 120°(+90°～ -30°)

Configuration of High Frequency Mobile C-arm System EKONCX38:
