Mobile medical radiographic X-ray system EKONDR06
MODEL / EKONDR06Mobile unit EKONDR06 distinguishes itself from the other mobile units presented into the international market, by its mechanical simplicity, its lightness, its handling, its practicalness.
- Mobile unit EKONDR06 distinguishes itself from the other mobile units presented into the international market, by its mechanical simplicity, its lightness, its handling, its practicalness.
- 100 kHz/30kW power, with a maximum a/c absorption of 12A only, it represents the best available nowadays to make any X-ray exams in emergency rooms or in hospital rooms even with a normal 230V single phase electric mains
- The two points technique (kV/mAs), the programmed anatomical technique (40 storage programs), the control panel with liquid crystals display of the data and messages, the control electronics with microprocessor are the prerogatives for the maximum facility using and for the maximum time reliability
- EKON Medical cooperate with DHL,FEDEX,UPS,EMS,TNT,etc.International shipping company,make your goods? arrive destination safely and quickly.
Product Details
Quick Details
Mobile unit EKONDR06 distinguishes itself from the other mobile units presented into the international market, by its mechanical simplicity, its lightness, its handling, its practicalness.
Specifications
Mobile medical radiographic X-ray system EKONDR06
Mobile unit EKONDR06 distinguishes itself from the other mobile units presented into the international market, by its mechanical simplicity, its lightness, its handling, its practicalness.
Mobile medical radiographic X-ray system EKONDR06
Mobile medical radiographic X-ray system EKONDR06 features:
1.Mobile unit EKONDR06 distinguishes itself from the other mobile units presented into the international market, by its mechanical simplicity, its lightness, its handling, its practicalness.
2. 100 kHz/30kW power, with a maximum a/c absorption of 12A only, it represents the best available nowadays to make any X-ray exams in emergency rooms or in hospital rooms even with a normal 230V single phase electric mains
3. The two points technique (kV/mAs), the programmed anatomical technique (40 storage programs), the control panel with liquid crystals display of the data and messages, the control electronics with microprocessor are the prerogatives for the maximum facility using and for the maximum time reliability
MSL TEAM picture
Welcome to medicalequipment-msl.com,If you have any demand in ultrasound machine.
Technical Specifications
Technical parameters from the currently available product information.
| Item | Technology Parameter | |||
| Generator | Normal Power | 30kW | ||
| Invertion frequency | 100kHz | |||
| Exposure kVp | 40-125 kVp | |||
| Max Exposure Ma | 425mA | |||
| Max mAs | 200mAs | |||
| Power, Voltage | 1phase, AC220V±10% 50Hz | |||
| X-ray tube | Focus | 0.6/1.3mm | ||
| Voltage | 130kV | |||
| MAX.CONTIN.HEAT DISSPATION | 300W | |||
| ANODE HEAT STORAGE CAPACITY | 107kHU | |||
| Power | 11kW/32kW | |||
| Anode rotating speed | 3000rpm | |||
| Collimator | Operation mode | Manual | ||
| luminance | ＞150lux | |||
| Light field size | 43cm*43cm@SID=110cm | |||
| Mobile rack | X ray tube rotate right and left | ±90° | ||
| X ray tube rotate around column | ±90° | |||
| X ray tube rotate front and back | -20°~105° | |||
| X ray tube focus to floor distance | 480mm-2000mm | |||
Specifications can vary by configuration. Confirm intended use, final model, and supply details with our product team.
