Portable pet dog incubator for animal hospital EKONDW01 Plus

Quick Details

Providing much more cost efficiency for all the veterinarian pratices and breeding kennels.Internal nebulizer has been removed, extra external nebilizer is available as optional part.

Specifications

Portable pet dog incubator for animal hospital EKONDW01 Plus

Providing much more cost efficiency for all the veterinarian pratices and breeding kennels.Internal nebulizer has been removed, extra external nebilizer is available as optional part.

China pet incubator for animal hospital EKONDW01 Plus

The mechanism adopts "dual duct and double circulation convective thermal regulation" to create an excellent and bacteria-free therapeutic environment and young pet incubation environment similar to that provided pet parent (accompanied by purified air and proper temperature and humidity control).

Furthermore, it is equipped with a unique cabinet structure and double-layer thermostat cover, which can prevent loss of heat and radiant heat when nursing the pets. In addition, a temperature and humidity display device is provided, measuring current temperature with the set temperature clearly visible. The heating control adopts dual duct and double circulation convection heating technology. This prevents rapid change in temperature minimizing the shock that can be caused. It ensures that temperature of the ICU can rise evenly and gently. The Thermostat System adopts PID control technology, which can solve the problem of inertia temperature error comprehensively, thus the temperature control is more accurate and more energy efficient.

China pet incubator for animal hospital EKONDW01 Plus

1) Power supply voltage: 220V±10%/50Hz±2%

2) Input power: ≤400VA

3) Ambient temperature: 10°C ~ 35°C

4) Temperature control range

Cabinet temperature: 15°C ~ 38°C (can be up to 39°C by special operations)

5) Temperature fluctuation: ≤0.8°C

6) Average temperature of monitoring chamber: ≤1.0°C

7) Cabinet temperature control accuracy: ≤±0.5°C

8) Temperature rise time: 5min ~ 20min

9) Noises in monitoring room: ≤30dB

10) Whole machine earth leakage current: ≤0.5 mA (normal state) ≤1 mA (single fault state)

11) Withstand voltage: 1500V/50Hz, lasted one minute without breakdown and flashover.

12) Ambient conditions:

① Transportation and storage:

a. Ambient temperature: -10°C~40°C

b. Relative humidity: ≤95%

② Operating conditions:

a. Ambient temperature: 18°C ~ 30°C

b. Relative humidity: 30% ~ 75%
