Professional 100 mA Mobile X-ray Unit Equipment EKONMX15 vx05 for sale

Quick Details

X-ray generator: Stationary anode, single focus, and bridge silicon rectification, The X-ray generator is an oil-immersed self-cooled unit. Max rated capacity Current:15mA 30mA 60mA 100mA Voltage:90kVp 90kVp 90kVp 80kVp Time: 6.3s 6.3s 4.0s 3.2s Power supply: Voltage:180~240V

Specifications

Features of 100 mA Mobile X-ray Unit Equipment EKONMX15 vx05:

1.Remote control exposure device. 2.Used in ward and emergency treatment room for radiography. 3.Combined X-ray generator. 4.Single focus, full-wave rectifier. 5.Single-chip microcomputer controls and convenient service. 6.Liquid crystal display and error can be automatic warned.

Specification of 100 mA Mobile X-ray Unit Equipment EKONMX15 vx05:

1.X-ray generator: Stationary anode, single focus, and bridge silicon rectification, The X-ray generator is an oil-immersed self-cooled unit. 2.Max rated capacity Current:15mA 30mA 60mA 100mA Voltage:90kVp 90kVp 90kVp 80kVp Time: 6.3s 6.3s 4.0s 3.2s 3.Power supply: Voltage:180~240V Frequency:50Hz Power:not lower than 7kVA Resistance:not larger than 1Ω 4.Voltage adjustment range of x-ray tube:50~90kVp 5.Range of the timer:0.08~6.3s 6.Distance between the focus to the ground: 700~1780mm 7.X-ray tube focus transverse rotation: ±60o 8.Specification of X-ray tube:Model XD4 2.9/100 fixed anode,single focus 1.8/4.3mm 9.Transport dimension (L*W*H)(mm) 1230*900*2050 10.Weight(kg) Net:159/Gross:256
