Silicone Heating Pharmaceutical Freeze Dryer Equipment EKONFV04 with low price

Quick Details

EKONFV04 (silicone oil heating) freeze dryer. It changes the cumbersome operation of the past drying process, prevents material contamination, and automates the drying and sublimation. This model has shelf heating and programmable functions, can remember the freeze-drying curve, and comes with u disk extraction function, which is convenient for users to observe the lyophilization process of materials.

Specifications

Vacuum freeze dryers are widely used in the fields of medicine, pharmaceuticals, biological research, chemicals and food. The lyophilized articles are easy to store for a long time, and can be restored to the state before lyophilization and maintain the original biochemical characteristics after adding water.

EKONFV04 (silicone oil heating) freeze dryer. It changes the cumbersome operation of the past drying process, prevents material contamination, and automates the drying and sublimation. This model has shelf heating and programmable functions, can remember the freeze-drying curve, and comes with u disk extraction function, which is convenient for users to observe the lyophilization process of materials.

Technical parameters of EKONFV04 common vacuum freeze dryer:

1. The company's patented product square warehouse in-situ vacuum freeze dryer, pre-freezing, drying in-situ, easy to operate, good drying effect. 2. The drying chamber door is made of ACRYLIC material, which is colorless, transparent and observable for lyophilization. 3. Inflatable (discharge) valve adopts safety diaphragm valve, which can be connected to inert gas source, and is filled with inert gas after drying to extend the shelf life of the material. 4. Gas guiding technology, the ice trap is evenly caught in the cold trap, and the ice trapping ability is strong. 5. Internationally renowned brand compressors, high efficiency, energy saving, long service life and low noise. 6. The shelf temperature difference is small, the temperature control precision is high, and the drying effect is even. 7. Freeze-drying curve optimization control technology, which can control the cooling rate during the pre-freezing stage, and control the heating rate of the sample and the vacuum value of the current stage in the sublimation and analytical drying stages. 8. Powerful sensor calibration to ensure accurate measurement of long-term use. 9. 7-inch true color industrial embedded touch screen, showing the drying curve. 10. PID control, can store 20 programs, each program can be set to 36 segments, the freeze dryer can modify the program parameters during the operation process to improve the process optimization rate. 11. Intelligent data recording system, real-time recording and display of cold trap temperature curve, sample temperature curve, vacuum curve, optional USB interface to export data can be browsed by computer and a variety of operations, to facilitate process optimization and drying effect verification. 12. Flexible manual + automatic control mode, manually used for groping process, automatically used for batch production. EKONFV04 ordinary vacuum freeze dryer features application: Suitable for freeze drying of conventional materials in bulk (liquid, paste, solid).

Technical Parameters

Model EKONFV04 silicone heating function Drying Area（㎡） 0.1 shelf layers 1 shelf temperature range -40℃ to 50℃ shelf size（mm) 280*400mm cold trap temperature ≤ -50 °C water-capture capability 2kg/24h panel mounted liquid 1.5L Ultimate vacuum ≤ 10Pa Top-press (optional) Top-press （optional） Cooling Air cooling,room temperature<25℃ Dimensions(mm) 880*660* 550 Machine weight 100kg Voltage 220V 50hz /110V 60hz
