Touch Portable Veterinary Ultrasound Scanner Machine EKONVU40
MODEL / EKONVU40Touch Portable Veterinary Ultrasound Scanner Machine EKONVU40. Fireproofing and anti‐corrosion ABS
- 15' ' high resolution LCD monitor with tilting to view it freely and comfortably
Product Details
Quick Details
System Dimension: Height: 402 mm Width: 385mm Depth: 53mm
Weight: Around 4.5 kg (Include Battery)
Materials of systems Fireproofing and anti‐corrosion ABS
Specifications
Touch Portable Veterinary Ultrasound Scanner Machine EKONVU40
System Dimension:
Height: 402 mm Width: 385mm Depth: 53mm
Weight: Around 4.5 kg (Include Battery)
Materials of systems Fireproofing and anti‐corrosion ABS
Monitor: 15' ' high resolution LCD monitor with tilting to view it freely and comfortably Resolution: 1024×768 Brightness Adjustable Max Opening Angle:45°
Touchscreen: Fully resistive touch screen
Transducer element:128
Power:System operates via AC power & battery
AC Adapter: Model:MSL‐15AD Voltage: 100‐240VAC Frequency: 50/60 Hz Currency: 5A Output: 15V
Operating Evironment: Temperature: 0‐40 °C Humidity: 30%‐85% (non‐condensing) Pressure: 700hPa‐1060hPa
Storage and Transport: Temperature: ‐20‐55 °C Humidity: 30%‐95%(non‐condensing) Pressure: 700hPa‐1060hPa
Technical Specifications
Technical parameters from the currently available product information.
- Height
- 402 mm Width: 385mm Depth: 53mm
- Resolution
- 1024×768
- Max Opening Angle
- 45°
- Transducer element
- 128
- Power
- System operates via AC power & battery
- Voltage
- 100‐240VAC
- Frequency
- 50/60 Hz
- Currency
- 5A
- Output
- 15V
- Battery
- (optional)
- Charge to Full
- 6 hours
- Max Duration
- 180 minutes realtime scan *
- Temperature
- 0‐40 °C
- Humidity
- 30%‐85% (non‐condensing)
- Pressure
- 700hPa‐1060hPa
Specifications can vary by configuration. Confirm intended use, final model, and supply details with our product team.
